Cnc Lathe TAKISAWA TA 25 Y BT
Sold
Cnc Lathe TAKISAWA TA 25 Y BT
Location:Italy
Description
Cnc Lathe TAKISAWA TA-25 Y BT, Cnc FANUC 18-T, used machine in excellent conditions, available for immediate delivery Subject to Prior Sale.
Specifications
| Manufacturer | TAKISAWA |
| Model | TA 25 Y BT |
| Year | 1998 |
| Condition | Ottime |
| Swing over bed mm. | 650 |
| Turning diameter mm. | 260 |
| Swing over cross slide mm. | 330 |
| Center distance mm. | 660 |
| Main spindle chuck diameter mm. | 250 |
| Main spindle motor power Kw | 11 |
| Main spindle speed rpm | 40 - 4000 |
| Main spindle bar capacity mm. | 75 |
| Cnc | FANUC 18 T |
| Main spindle attachment | A2-8 |
| Subspindle diameter mm. | 165 |
| Subspindle rpm | 32 - 3200 |
| Subspindle power Kw | 7,5 |
| Subspindle bar passage mm. | 42 |
| Turret | 12 positions with driven tools |
| Driven tools power Kw | 3,7 |
| Driven tools rpm | 36 - 3600 |
| X mm. | 185 |
| Z mm. | 660 |
| B mm. | 620 |
| C degrees | 0,001 |
| Y axis mm. | 100 (+/- 50) |
| Accessories | Driven and normal Tooling |
| Conveyor | Yes |
| CE certificate | Yes |
| CE marked | Yes |
| Machine overall dimensions mm. | 3120 x 2247 x 2210 |
| Machine weight Kg | 5900 |
| Working hours | 3536 |
