Cnc Portal Gronder DANOBAT SGU-80/23/14

Cnc Portal Grinder DANOBAT SGU-80/23/14

Table size mm.8000 x 2500

X1 table travel mm.8600

Grinding width mm.2650

Passage between columns mm.3100

Grinding height mm.1400

Max table load Kg 32000

Y2 head cross travel mm.3520

W2 head vertical travel mm.1570

A1 Head angular stroke +/- 110°

Angle head indexing 2,5°

Wheel size dia mm.610 x 100 x dia 304,8

Minimum wheel size dia mm.450

Wheel motor power Kw 35

C2 Automatic wheel changer 2 positions

V2 Universal wheel dressing unit mm.260

U2 Universal wheel dressing unit mm.120

Cnc SIEMENS 840 D

MARPOSS measuring system

Full working area cover with automatic opening on one side for piece loading

Machine weight Kg.95000

Machine plant dimensions with cover mm.21440 x 6000

CE

Year 2010

Filtering unit with conveyor

Set of wheels

Flanges

Refrigerating unit

Installed and working

Perfect conditions

4000 working hours
